Rockwell Automation Publication 7000-UM202H-EN-P - November 2023 171
Chapter 3 Control Component Definition and Maintenance
TP22 DIAG_9 OIB B, RX4 Diagnostic Feedback
T
P23 CMD_9 OIB B, TX4 Firing Command Signal
TP24 DIAG_10 OIB B, RX5 Diagnostic Feedback
TP25 CMD_10 OIB B, TX5 Firing Command Signal
TP26 DIAG_11 OIB B, RX6 Diagnostic Feedback
TP27 CMD_11 OIB B, TX6 Firing Command Signal
TP28 TFB_B OIB B Temperature Feedback Signal
TP29 GND Ground Reference for TP16 – TP28
TP30 DIAG_12 OIB C, RX1 Diagnostic Feedback
TP31 CMD_12 OIB C, TX1 Firing Command Signal
TP32 DIAG_13 OIB C, RX2 Diagnostic Feedback
TP33 CMD_13 OIB C, TX2 Firing Command Signal
TP34 DIAG_14 OIB C, RX3 Diagnostic Feedback
TP35 CMD_14 OIB C, TX3 Firing Command Signal
TP36 DIAG_15 OIB C, RX4 Diagnostic Feedback
TP37 CMD_15 OIB C, TX4 Firing Command Signal
TP38 DIAG_16 OIB C, RX5 Diagnostic Feedback
TP39 CMD_16 OIB C, TX5 Firing Command Signal
TP40 DIAG_17 OIB C, RX6 Diagnostic Feedback
TP41 CMD_17 OIB C, TX6 Firing Command Signal
TP42 TFB_C
OIB C Temperature Feedback Signal – There is no provision in the drive
for the use of this signal, it is only provided for Rockwell internal testing.
TP43 GND Ground Reference for TP30 – TP42
Table 19 - Test Points on Optical Interface Base Board (OIBB) (Continued)
Test Point Signal Name Description
