Controller functions
Page 40 RES-445
• In addition, as of software revision 100:
K1 is energized if the actual value is inside the
specified temperature tolerance band
(steps 207, 208). The relay remains energized at
the end of the heatsealing cycle and is not deen-
ergized again until the next "START" signal is
activated.
Relay K1 active if Tact =
Tset, with latch function
Time control ON:
• K1 is not activated Relay K1 OFF
• K1 is energized if the start signal is present. The
relay is deenergized at the end of the cooling
phase.
Relay K1 active when
START signal present
• K1 is energized if the actual value reaches 95%
of the set point. The relay is deenergized at the
end of the cooling phase.
Relay K1 active when
temperature reached
• K1 is energized at the end of the heating phase
and deenergized again at the end of the cooling
phase.
(This setting is possible as of software
revision 010)
Relay K1 active during
cooling phase
• K1 is energized for up to 0.5 seconds at the end
of the cooling phase (momentary impulse). The
length of the momentary impulse can be shor-
tened by applying the start signal (during the
impulse).
Relay K1 generates end-
of-cycle impulse
• In addition, as of software revision 100:
K1 is energized if the actual value is inside the
specified temperature tolerance band
(steps 207, 208).
Relay K1 active if Tact =
Tset
• In addition, as of software revision 100:
K1 is energized if the actual value is inside the
specified temperature tolerance band
(steps 207, 208). The relay remains energized at
the end of the heatsealing cycle and is not deen-
ergized again until the next "START" signal is
activated.
Relay K1 active if Tact =
Tset, with latch function
213 Lock of "HAND" key You can specify here whether or not the heatsealing
band can be heated in the home position by pres-
sing the "HAND" key.
ON,
OFF
214
[30]
Cycle counter The number of heating impulses (not manual
impulses) is counted and displayed with this menu
step. The counter can be reset either by pressing
the "ENTER" key or by restoring the factory set-
tings.
Reset with "ENTER" key
No. Name Description Setting range
