Controller functions
Page 42 RES-445
• Output 1 is energized if the actual value is inside
the specified temperature tolerance band
(steps 207, 208). The relay remains energized at
the end of the heatsealing cycle and is not deen-
ergized again until the next "START" signal is
activated.
"Output 1" active if Tact =
Tset, with latch function
Time control ON:
• Output 1 is not activated "Output 1" OFF
• Output 1 is energized if the start signal is pre-
sent. The relay is deenergized at the end of the
cooling phase.
"Output 1" active with
START signal
• Output 1 is energized when the actual value rea-
ches 95% of the set point. The relay is deener-
gized at the end of the cooling phase.
"Output 1" active when
temperature reached
• Output 1 is energized at the end of the heating
phase and deenergized again at the end of the
cooling phase.
(This setting is possible as of software revision
010)
"Output 1" active during
cooling phase
• Output 1 is energized for up to 0.5 seconds at
the end of the cooling phase (momentary
impulse). The length of the momentary impulse
can be shortened by applying the "START"
signal (during the impulse).
"Output 1" generates end-
of-cycle impulse
• Output 1 is energized if the actual value is inside
the specified temperature tolerance band
(steps 207, 208).
"Output 1" active if Tact =
Tset
• Output 1 is energized if the actual value is inside
the specified temperature tolerance band
(steps 207, 208). The relay remains energized at
the end of the heatsealing cycle and is not deen-
ergized again until the next "START" signal is
activated.
"Output 1" active if Tact =
Tset, with latch function
225 Temperature unit Unit for temperature display and input values Celsius
Fahrenheit
No. Name Description Setting range
