Reference Manual
00809-0100-4130, Rev AA
May 2009
Rosemount 2130
A-12
7K DN65, PN 10/16 flange
7L DN65, PN 25/40 flange
7M DN65, PN 63 flange
7N DN65, PN 100 flange
3K DN80, PN 10/16 flange
3L DN80, PN 25/40 flange
3M DN80, PN 63 flange
3N DN80, PN 100 flange
4K DN100, PN 10/16 flange
4L DN100, PN 25/40 flange
4M DN100, PN 63 flange
4N DN100, PN 100 flange
Other Process Connection
XX
(5)
Customer specific
Code Electronic Type
L Direct Load Switching (Mains 2-wire) 24 to 264 Vac, 50/60 Hz, 24 to 60 Vdc, Self-checking
P PNP/PLC Low Voltage (3-wire) 24 to 60 Vdc, Self-checking
D Relay (DPCO), Self-checking
N NAMUR, Self-checking
Code Surface Finish (Wetted Parts) Available for Connections Available for Housing
1 Standard surface finish
All All
2 Hand polished (Ra < 0.8 µm)
Hygienic Fittings Only All
Code Product Certifications Available for Electronic Type Available for Housing
NA No Hazardous Locations Certifications
All All
G5
(6)
FM Ordinary Locations (Safe Area)
All Y, T
G6
(7)
(8)
CSA Ordinary Locations (Safe Area)
All Y, T
E1 ATEX Flameproof
All X, S
E3 NEPSI Explosion-proof
All X, S
E5 FM Explosion-proof
All Y, T
E6
(8)
CSA Explosion-proof
All Y, T
E7 IECEx Explosion-proof
All X, S
I1 ATEX Intrinsic Safety
NAll
I3 NEPSI Intrinsic Safety
N All
I5 FM Intrinsic Safety
N All except X and S
I6
(8)
CSA Intrinsic Safety and Non-Incendive
N All except X and S
I7 IECEx Intrinsic Safety
NAll
Code Housing Available for Certifications
X Aluminum Alloy, M20 conduits/cable threads
NA, E1, E3, E7, I1, I3, I7
Y Aluminum Alloy,
3
/4-in. NPT conduits/cable threads
NA,E5,E6,G5,G6,I1,I3,I5,I6,I7
S Stainless Steel, M20 conduits/cable threads
NA, E1, E3, E7. I1, I3, I7
T Stainless Steel
3
/4-in. NPT conduits/cable threads
NA,E5,E6,G5,G6,I1,I3,I5,I6,I7
Code Fork Length Available Connection
A Standard length 1.7 in. (44 mm)
All except flanged models
H
(3)
Standard length flange 4.0 in. (102 mm)
Flanged models only
0000 Factory default length (only if fork length A or H is selected)
Specific Extended Fork Length
E
(9)
Extended, Customer Specified Length in tenths of Inches
All except code 1P
M
(9)
Extended, Customer Specified Length in millimeters
All except code 1P
