Rosemount 2130
xxxx
(9)
Specific customer specified length in inches or mm (only if fork length E or M is selected)
Code Options
Calibration Data Certification
Q4 Certificate of Functional Test
Material Traceability Certification
Q8
(2) (3)
Material Traceability Certification per EN 10204 3.1B
Special Procedures
P1
(10)
Hydrostatic Testing with Certificate
Low Liquid Density Range
LD Minimum 31.2 lb/ft
3
(500 kg/m
3
)
Tag Plates
ST Tag plate SST engraved plate (maximum 16 digits)
WT Tag plate laminated paper (maximum 40 digits)
Typical Model: 2130 D 0A L 1 NA A A 0000 Q8 ST
(1) Flanges are dual certified 316 and 316L Stainless Steel (1.4401 and 1.4404).
(2) Only available for wetted parts.
(3) Option is not available for hand polished wet side as standard.
(4) Only available of BSPT and NPT threaded process connection code 0A, 0D, 1A, and 1D as standard, other upon request.
(5) Other process connections available upon request.
(6) See “Product Certifications” on page B-1. E5 includes G5 requirements. G5 is for use in unclassified, safe area locations only.
(7) See “Product Certifications” on page B-1. E6 includes G6 requirements. G6 is for use in unclassified, safe area locations only.
(8) Rosemount 2130 CSA approved vibrating fork level switch models 2130***G6**, 2130***E6** and 2130***I6** when configured with 316L Stainless Steel
(1.4404) wetted parts and either NPT threaded process or ASME B16.5 2-in. to 8-in. flanged process connections meet the requirements of CRN.
(9) Example: Code E1181 is 118.1 inches. Code M3000 is 3000 mm. See “Extended Lengths” on page A-1 for minimum and maximum extended lengths.
(10) Option is limited to units of no more than 59.1-in. (1500 mm) extended lengths.
