Reference Manual
00809-0100-4130, Rev AA
May 2009
B-5
Rosemount 2130
Factory Mutual (FM) Intrinsically Safe Approval
I5 Project ID: 3024095
Intrinsically Safe for Class I, Div. 1, Groups A, B, C, and D
Class I, Zone 0, AEx ia IIC
Temperature Code:
T5 - See Control Drawing
Control Drawing: 71097/1154 (Figure B-1 on page B-7)
Ui=15 V, Ii=32 mA, Pi=0.1 W, Ci=211 nF, Li=0.06 mH
NOTE
A NAMUR isolating amplifier must be used for intrinsic safety.
Canadian Standards Association (CSA) Intrinsically Safe Approval
I6 Certificate Number: 06 CSA 1878089
Intrinsically Safe for Class I, Div. 1, Groups A, B, C, and D
Class I, Zone 0, Ex ia IIC
Temperature Code:
T5 - See Control Drawing
Control Drawing: 71097/1179
Ui=15 V, Ii=32 mA, Pi=0.1 W, Ci=211 nF, Li=0.06 mH
NOTE
A NAMUR isolating amplifier must be used for intrinsic safety.
Canadian Standards Association (CSA) Non-Incendive Approval
I6 Certificate Number: 06 CSA 1878089
Non-Incendive for Class I, Div. 2, Groups A, B, C, and D
Temperature Code:
T5 - See Control Drawing
Control Drawing: 71097/1179 (Figure B-2 on page B-8)
Ui=15 V, Ii=32 mA, Pi=0.1 W, Ci=211 nF, Li=0.06 mH
NOTE
A NAMUR isolating amplifier must be used for compliance with the non-incendive
approval.
Instructions specific to hazardous (classified location) area installations
Model numbers covered:
2130***C*I5A*, 2130***C*I5D*, 2130***C*I6A*, 2130***C*I6D*
(“*” indicates options in construction, function and materials.)
The following instructions apply to equipment covered by FM and CSA Approvals:
1. The Intrinsically Safe approved Rosemount 2130 may be used in hazardous
locations with flammable gases and vapors Class 1 Division 1 Groups A,B,C, and
D, and Class 1 Zone 0 Group IIC when installed in accordance with control drawing
71097/1154 (Figure B-1 on page B-7), or 71097/1179 (Figure B-2 on page B-8).
2. The Non-Incendive approved Rosemount 2130 may be used in hazardous
locations with flammable gases and vapors Class 1 Division 2 Groups A, B, C, and
D when installed in accordance with control drawing 71097/1179 (Figure B-2 on
page B-8).
