9.1.8. RJ45 Cable Compensation
The technology employed to transmit full-rate, high-definition video over an RJ-45 cable
may require an initial setup to ensure the highest possible image quality. Shorter cables
(0-6 feet) and cables with different impedance characteristics than the Rosen-specified
Siemon RJ-45 cable may benefit from turning off RJ45 Cable Comp. If the installed
remote display system exhibits video anomalies, turning off cable compensation is
recommended.
 RJ45 Cable Comp ON for RJ-45 cable length 7-50 feet (default setting)
 RJ45 Cable Comp OFF for RJ-45 cable length 0-6 feet
Highlight AdvancedRJ45 Cable Comp and press ENTER.
Use the ▲▼ buttons to set the option and then press ENTER.
Select Back to return to the Technician Menu.
Press EXIT to exit the OSD.
9.2. Power Mode
Use Power Mode to set display’s on/off state.
From the Technician Menu, press the ▼ button to select Power Mode and then press ENTER.
Use the ▲▼ buttons to set the option and then press ENTER.
Options include the following:
 Auto-On: The display always starts up in the ON state when 28V is applied (default).
 Auto-Off: The display always starts up in the standby state when 28V is applied.
 Restore Previous: The display returns to the previous power settings after any power
interruption.
 Ground-On: The display always starts up in the ON state when the power pin is
grounded and ignores all power commands from the IR, RS-232, and RS-485. This
setting will not take effect until you close the OSD.
 Open-On: The display always starts up in the ON state when the power pin is open
(not grounded) and ignores all power commands from the IR, RS-232, and RS-485.
This setting will not take effect until you close the OSD.
 Momentary: The LCD power will toggle between on and off after the external power
discrete is momentarily grounded.
Select Back to return to the Technician Menu.
Press EXIT to exit the OSD.
