Rosen Aviation Remote Display System User Manual

Rosen Aviation Remote Display System
Document Number: 105478
Revision: A
Date: 04/24/12
Template: 4.2.3-6-FM; Revision A; 16 May, 2005
Page 36 of 43
Table 4 Technical references
Product
Part Number
Location
Universal Color Remote Control
Contact Rosen Sales for part number availability
RS-232 7-button External Controller
0300-408
www.rosenaviation.com
External IR Receiver
0500-006
www.rosenaviation.com
If you need assistance in configuring a universal remote control to work with a remote display
system, please contact Rosen Aviation Technical Support at 541.342.3802.
10.2. Cleaning the Display
Clean the LCD with a lens-grade tissue for cleaning optical surfaces and isopropyl alcohol.
10.3. RTCA DO-160F Qualifications for Displays
The table below shows the DO160 compliance of the remote display system, unless otherwise
noted. Omitted categories are not applicable to this product or its expected installation.
Table 5 DO 160 Level F test criteria on an 0700-104 RMEB MOD 01 with a display monitor connected
Description
Section
Category
Comments
Temperature and Altitude
4
Ground Survival/Short-Time Operating
Low Temp
4.5.1
A1
Operating Low Temperature
4.5.2
A1
Ground Survival/Short-Time Operating
High Temp
4.5.3
A1
Operating High Temperature
4.5.4
A1
In-flight Loss of Cooling
4.5.5
–
Not applicable
Altitude
4.6.1
A1
Decompression
4.6.2
A1
8000 – 50,000 ft.
Overpressure
4.6.3
A1
Temperature Variation
5
Temperature Variation
5.3.1
C
Humidity
6
Humidity
6.3.1
A
Operational Shocks & Crash Safety
7
Operational Shocks
7.2.1
B
Crash Safety (Impulse)
7.3.2
B
Crash Safety (Sustained)
7.3.3
B
Vibration
8
Random Vibration – Fixed Wing Aircraft
8.5.2
S (Curve B)
Magnetic Effect
15

Rosen Aviation Remote Display System Specifications

General

Brand	Rosen Aviation
Model	Remote Display System
Category	Monitor
Language	English
