Rosen Aviation Remote Display System User Manual

Rosen Aviation Remote Display System
Document Number: 105478
Revision: A
Date: 04/24/12
Template: 4.2.3-6-FM; Revision A; 16 May, 2005
Page 38 of 43
Description
Section
Category
Comments
25.853 Appendix F
10.3.1. Other Certification Considerations for RDMs
Description
Comments
Static Abuse Load (300 lbs.)
Testing in accordance with DO 313 section 4.2(a), Glass
in the Cabin
Mechanical Strength (Ball Impact)
Testing in accordance with UL 61965
Inertia Loads
Testing in accordance with 14 CFR 25.561(b) (3)
10.4. Specifications
Table 6 Remote Monitor Electronics Box performance specifications
Video inputs
See sections below for supported resolutions
Inrush Peak
20 A
Op Voltage Range
18-32 VDC
Weight
2.85 lbs [1.3 kgs.] ± 5%
Nominal Voltage/Current Draw
See appropriate-sized RDM spec table below
Operating Temperature
-15ºC – 55ºC (stand-by mode below 0º and above 50ºC)
Table 7 19” Remote Display Module performance specifications
Screen size
19” diagonal, 16x10 format
Native Resolution
1440 x 900
Video inputs
See sections below for supported graphic resolutions
Viewing Angles:
Horizontal and Vertical
Horiz: ±80º
Vert: ±80º
Screen Brightness
300 cd/m
2
typical
Contrast Ratio
1000:1
Color Depth
8 bits
Weight (RDM only)
7.1 lbs [3.2 kgs.] ± 10%
System Nominal Voltage/Current Draw
28VDC/1.3 A (includes RMEB and RDM)
Power Dissipation
RMEB: 14W
RDM: 23W
Operating Temperature
-15ºC to 55ºC (stand-by mode below 0º and above 50ºC)
Table 8 24” Remote Display Module performance specifications
Screen size
24” diagonal, 16x9 format
Native Resolution
1920 x 1080
Video inputs
See sections below for supported resolutions
