Page #5 background imageLoading...
Page #5 background image
Rosen Aviation Remote Display System
Document Number: 105478
Revision: A
Date: 04/24/12
Template: 4.2.3-6-FM; Revision A; 16 May, 2005
Page 5 of 43
1. INTRODUCTION
Rosen’s Remote Display System consists of an ultra-thin remote display module and a high-
definition remote electronics box. The remote electronics design provides more mounting options
because the video processing electronics box can be located up to 50 feet from the display. The
high-definition display modules are available in a range of sizes and mounting options that allow
customers to configure a system that fits their aircraft’s cabin interior.
This manual provides general instructions about how to install all bulkhead configurations of the
Remote Display System onto your aircraft. It contains everything you need to know to wire the
components and confirm that the system is functioning correctly.
Note: Only trained and qualified personnel should perform installation and service.
1.1. Remote Display Modules
The Remote Monitor Electronics Box (RMEB) will operate one Remote Display Module (RDM),
regardless of the size. Remote Display Modules have three distinct mounting options flush
mount, semi-proud mount, and proud mount configurations and they are available in the
following sizes:
19”
24”
26”
32”
1.2. System Components
To learn more about the following Remote Display System components and to access the
drawings, visit our website at www.rosenaviation.com.
Remote Monitor Electronics Box (P/N 0700-104 MOD 01)
Remote Display Modules (RDM) by size
Mounting accessories: bezel, cosmetic back, and credenza
From the Rosen Aviation home page, select the ProductsDisplaysHigh Definition
Displays tab and browse by product size. For more information about a remote display system,
please contact Rosen Sales or Technical Support.
1.2.1. IR Remotes
The RMEB provides 5V @100mA output to power an external IR receiver. The remote
monitors do not have a built-in IR sensor. The following options (sold separately) enable
remote inputs with the Remote Display System and adjust the on-screen display settings:
External IR Receiver (P/N 0500-006)
Universal color display remote control (contact Rosen Sales for P/N availability)
Note: For directions on operating the optional universal remote control, refer to the user’s
guide enclosed with the remote.
