Rosen Aviation Remote Display System User Manual

Rosen Aviation Remote Display System
Document Number: 105478
Revision: A
Date: 04/24/12
Template: 4.2.3-6-FM; Revision A; 16 May, 2005
Page 42 of 43
PAL
Phase Alternating Line. A video standard used in Europe, China, Malaysia,
Australia, New Zealand, the Middle East, parts of Africa, and other parts of
the world.
PCB
Printed Circuit Board – an electronics assembly that performs tasks
P/N
Part Number
RDM
Remote Display Module
RF
Radio frequency
RGB
Red, Green, Blue
RMEB
Remote Monitor Electronics Box
RS-232
Standard for serial binary data interchange
RS-485
Standard for allowing multiple devices to share a common set of serial data
communication lines.
RTCA
Radio Technical Commission for Aeronautics
SECAM
(Séquentiel couleur à mémoire.) French for "sequential color with memory,"
an analog color video system first used in France.
SDI
Serial digital interface
SVGA
Super Video Graphics Array
SXGA
Super Extended Graphics Array
UXGA
Ultra Extended Graphics Array
VDC
Volts direct current – voltage from an aircraft battery or generator
VGA
Video Graphics Array
Vpp
Volts peak-to-peak
W
Watts
WSXGA
Widescreen Super Video Graphics Array
WUXGA
Widescreen Ultra eXtended Graphics Array
XGA
Extended Graphics Array
YPbPr
Analog video signal carried by component video cable in consumer
electronics. Y carries luma (brightness) information. Pb carries the difference
between blue and luma (B − Y). Pr carries the difference between red and
luma (R − Y).
