PRINTER
The figure below shows the printer with the cover removed.
DESCRIPTION OF PART FUNCTION
1. Paper Roll The paper roll is located here.
2. Paper Entrance The end of the paper is inserted into the printer here.
3. Paper Guide Used to guide the journal paper.
4. Journal Spindle Support Used for the journal spindle (take-up spool) to take up the journal paper used
for record keeping.
5. Paper Exit The paper exits here.
6. Battery Compartment Used for 3 "AA" batteries to back up the memory.
7. Ribbon Cartridge Used to supply ink to the printer.
9
