Web-based Configuration Guide Fast Internet Access
13
In this mode, the device enables multiple users to share Internet connection from WISP. The LAN port devices
share the same IP from WISP through Wireless port. While connecting to WISP, the Wireless port works as a
WAN port. The Ethernet port acts as a LAN port
Note
In the WISP mode, the device still supports routing and DHCP. The clients connected to the primary router are
assigned IP addresses by the primary router; the clients connected to the secondary router are assigned IP
addresses by the secondary router.
(1) Click WISP. Select the Wi-Fi of the primary router.
(2) Enter the password of the primary router Wi-Fi.
○ Select DHCP and the extender will automatically obtain an IP address.
○ If the primary router cannot assign IP addresses, select Static IP.
○ In the PPPoE mode, a username, a password, and possibly a service name are needed.
