CompTrol Interface V4.0.x | Issue 21-05-2021 | 1000932 107
Technical data
21 Technical data
Supply voltage - Via external electrical supply 24 V DC
- Via X/Y remote control bus 18 V DC
Nominal current - Max. 60 mA, for external electrical supply 24 V DC
- Max. 80 mA, for electrical supply via
X/Y remote control bus 18 V DC
Power consumption 1.44 W
Protection class III, if U
in
< 50 V
Protective ground Not permitted
Length of connecting cable to
indoor unit Max. 120 m
Digital inputs:
–
Quantity
–
Input voltage U
in
6
20 to 130 V DC or 24 to 230 V AC, shared neutral wire
Analog input:
–
Quantity
–
Input range
–
Max. input voltage
–
Impedance
1
0 to 5 V DC, 0 to 10 V DC, 0 to 20 mA, 4 to 20 mA
+/-50 V DC
75 kΩ
Digital outputs:
–
Quantity
–
Volt-free contacts
–
Isolation voltage
3
130 V DC, 0.5 A; 230 V AC, 0.5 A, ohmic load only
1.5 kV against all other inputs/outputs
Bus connections:
–
Quantity
–
Design
2
RJ45
Displays:
–
Status display of digital inputs
–
Status display of digital
outputs
–
Operating signals
6 yellow LEDs
3 yellow LEDs
Three 7-segment displays, see “4.7 7-segment display” on page 21
Cable requirements See “17.3 Cable requirements” on page 96
Max. number of indoor units 16
Operation Conguration via DIP switches
Mounting On TS DIN rail 35 mm x 7.5 mm (to DIN EN 60715),
horizontal installation
Installation location Indoor switch gear cabinet, distribution cabinet
Ambient conditions
–
Temperature
–
Air humidity
-20 °C to +80 °C
Max. 85 %, non-condensing
Dimensions (H x W x D) 80 mm x 116 mm x 36 mm (without holder)
Weight, net 190 g
Table 75: Technical data
