Safety
IMPORTANT
Dangerduetoincorrectlyconguredcomponents.
During setup and conguration, it may be necessary to congure further components for use with
the CompTrol Interface.
●
Before starting up, always check the current conguration of all a󰀨ected components such as
wired remote controls and compressors (also see the documentation of the respective com-
ponents).
IMPORTANT
Damage to the CompTrol Interface by reversing the polarity of terminals X5-(+) and X5-(-).
●
Ensure the correct polarity for terminals X5-(+) and X5-(-).
2.3 Requiredpersonnelqualications
All electrical work must be performed exclusively by authorized specialist electricians.
A specialist electrician is a person who, through their specialist training and experience, has the
skills required for
●
switching on/o󰀨, enabling, grounding, and marking electrical circuitry and equipment,
●
installing and conguring IT systems,
●
skilled maintenance and use of protective devices in accordance with the relevant safety
standards,
●
providing rst aid to injured persons.
2.4 Compatible products
The CompTrol Interface is compatible with the following products from Mitsubishi Heavy Indus-
tries and Stulz:
●
CompTrol Master (program 10, CompTrol Interface V4.0.3 and higher)
●
KX series air conditioning units from Mitsubishi Heavy Industries (programs 0 and 2 to 7)
●
FDS series air conditioning units from Mitsubishi Heavy Industries (programs 0 and 2 to 10)
●
S series air conditioning units from Mitsubishi Heavy Industries (programs 0 and 2 to 10)
●
SX series air conditioning units from Mitsubishi Heavy Industries (programs 0 and 2 to 7)
●
FDX and FDXL heat exchanger connection modules (programs 0 and 2 to 10)
●
FDSX and FDSXL heat exchanger connection modules (programs 0 and 2 to 7)
●
CompTrol Signal DC expansion module (programs 0 and 4 to 10)
2.5 Other applicable documents
Besides this technical documentation, the following documents must also be observed:
●
CompTrol Master Technical Manual
●
Technical Manual for the FDX heat exchanger connection module
●
Technical Manual for the FDXL heat exchanger connection module
●
Technical Manual for the FDSX heat exchanger connection module
●
Technical Manual for the FDSXL heat exchanger connection module
●
KX series Technical Manual
●
FDS series Technical Manual
