CompTrol Interface V4.0.x | Issue 21-05-2021 | 1000932 33
Program 0 – temperature setpoint denition via analog signal
7.2.2 Setting program 0 on DIP switch S1
S1-1 S1-2 S1-3 S1-4 Designation
OFF OFF OFF OFF Program 0: Temperature setpoint denition via analog signal
Table 13: DIP switch setting for program 0
7.2.3 Setting the functions for program 0 via DIP switch S2
The following table lists the functions for program 0 in brief. See “5 Functions of the CompTrol
Interface expansion module” on page 23 for a detailed description of the functions.
DIP switch Status Function
S2-1
ON
OFF
CompTrol Interface is congured as master in the X/Y remote control bus
CompTrol Interface is congured as slave in the X/Y remote control bus
S2-2
ON
OFF
X4b-II, operating signal; X4c-III, heating signal
X4b-II, compressor signal; X4c-III, defrost signal
S2-3 OFF Inoperative, switch setting is always OFF
S2-4
ON
OFF
Automatic fan speed control
Inoperative
S2-5
ON
OFF
Forced mode
Inoperative
S2-6
ON
OFF
All digital outputs are closed without a signal (NC).
All digital outputs are open without a signal (NO).
S2-7
ON
OFF
Setting determines the value shown on the 7-segment display (see “4.7
7-segment display” on page 21).
S2-8
ON
OFF
Setting determines the value shown on the 7-segment display (see “4.7
7-segment display” on page 21).
Table 14: Functions in program 0
7.2.4 Setting the analog signal type on S4 and S7
The position of the jumpers on pin headers S4 and S7 determines the current analog signal type
(see “4.4.1 Analog input X3” on page 19).
7.3 Analog input
Note
If a signal exceeds or falls below a boundary value at analog input X3-S, the temperature set-
point 23 °C is transferred. (see “5.3.4 Signal boundary value monitoring” on page 27)
Analog input X3-S is only evaluated if a signal is applied to digital input X2b-D4 (see “5.1
Functions of analog input X3” on page 23).
