Program overview
6 Program overview
The CompTrol Interface o󰀨ers nine di󰀨erent programs for adapting the expansion module to indi-
vidual requirements. The programs are activated via DIP switches S1-1 to S1-4. You can nd the
precise DIP switch congurations in the section dealing with each program or as a summary in
“Table 7: Program selection via DIP switches” on page 21.
The following programs are available:
Program Description
Program 0 Temperature setpoint denition via analog signal
Program 2 Temperature setpoint denition with window contact function
Program 3 Temperature setpoint denition for equipment rooms with temperature limit alarm
Program 4 Temperature setpoint denition with hotel remote control function
Program 5 Temperature setpoint denition with lockout function
Program 6 Temperature setpoint denition for heat exchanger connection module
Program 7 Temperature setpoint denition without signal boundary value monitoring
Program 8 Direct frequency request
Program 9 Direct frequency request with cascading
Program 10 Direct frequency request with the CompTrol Master
Table 12: Program overview
