Functions of the CompTrol Interface expansion module
The required resistance values from row E24 are listed in the table below:
R1[Ω] R2[Ω] Temperaturesetpoint[°C]
5100 0 18
4700 200 18.5
4700 430 19
4300 620 19.5
4300 820 20
3900 1100 20.5
3600 1200 21
3600 1500 21.5
3300 1600 22
3000 1800 22.5
3000 2200 23
2700 2200 23.5
2400 2400 24
2200 2700 24.5
2200 3000 25
1800 3000 25.5
1600 3300 26
1500 3600 26.5
1200 3600 27
1100 3900 27.5
820 4300 28
620 4300 28.5
430 4700 29
200 4700 29.5
0 5100 30
Table 9: Resistance values for voltage dividers
5.2 Functions via the digital inputs
5.2.1 Evaluating the analog input
When a signal is applied to digital input X2b-D4, analog input X3-S is evaluated. Depending on
the program, the analog signal is translated into a temperature or frequency setpoint. If no signal
is applied to X2b-D4, the analog input is not evaluated. In this case, the corresponding setpoint
can be specied via the wired remote control.
Analog input evaluation is possible in the following programs:
– Program 0 and programs 2 to 9.
