CompTrol Interface V4.0.x | Issue 21-05-2021 | 1000932 17
Product description
No. Designation Description
5 X4c-III
Defrosting signal, heating signal, window contact signal, or temperature limit
alarm,
volt-free, up to 230 V AC / 130 V DC / 0.5 A / NO, can be inverted with S2-6
6 X2a-D1
Assignment depends on the program,
20 V DC to 130 V DC or 24 V AC to 230 V AC
7 X2a-D2
Assignment depends on the program,
20 V DC to 130 V DC or 24 V AC to 230 V AC
8 X2b-D3
Assignment depends on the program,
20 V DC to 130 V DC or 24 V AC to 230 V AC
9 X2b-D4
Assignment depends on the program,
20 V DC to 130 V DC or 24 V AC to 230 V AC
10 X2c-D5
Assignment depends on the program,
20 V DC to 130 V DC or 24 V AC to 230 V AC
11 X2c-D6
Assignment depends on the program,
20 V DC to 130 V DC or 24 V AC to 230 V AC
12 X2N-N, X2N-N Shared neutral wire for digital inputs D1 to D6
13 LD1 to LD6 Status display of digital inputs D1 to D6
14 S2 DIP switch for selecting program-dependent functions and the 7-segment display
15 S1
DIP switch for setting the relevant program, and also for setting the installed out-
door unit model in programs 8 and 9
16 DS1, DS2, DS3 7-segment display
17 S3 Button (inoperative)
18 X3-S, X3-(-RV) Analog input, analog signal to terminal S, GND to terminal -RV
19 S4
Pin header for setting the analog signal type (analog input X3)
(see “Table 6: Analog signal type” on page 19)
20 S7
Pin header for setting the analog signal type (analog input X3)
(see “Table 6: Analog signal type” on page 19)
21 X4
Bus connection for connecting to a CompTrol Master;
necessary in combination with CompTrol Master
22 X2
Bus connection for connecting to a CompTrol Master;
necessary in combination with CompTrol Master
23 S9 Pin header
24 S8 Pin header
25 LD11 to LD13 Status display for digital outputs X4a-I, X4b-II, and X4c-III
26 S5
Pin header for setting the electrical supply
(see “Table 5: Type of electrical supply” on page 18)
27 S6
Pin header for setting the electrical supply
(see “Table 5: Type of electrical supply” on page 18)
