S-Klima CompTrol - Page 5

CompTrol Interface V4.0.x | Issue 21-05-2021 | 1000932 5
8 Program2–temperaturesetpointdenition
with window contact function ................................................................................ 36
8.1 Description .......................................................................................................... 36
8.2 Conguring the CompTrol Interface for program 2 ............................................. 36
8.2.1 Connection diagram for program 2 ................................................................... 36
8.2.2 Setting program 2 via DIP switch S1 ................................................................ 38
8.2.3 Setting functions for program 2 via DIP switch S2 ............................................ 38
8.2.4 Setting the analog signal type on S4 and S7 .................................................... 38
8.3 Analog input ........................................................................................................ 38
8.4 Window contact function Auto ON ...................................................................... 40
8.5 Digital input assignment in program 2................................................................. 40
8.6 Digital output assignment in program 2 .............................................................. 41
9 Program3–temperaturesetpointdenitionforequipmentrooms
with temperature limit alarm ................................................................................... 42
9.1 Description .......................................................................................................... 42
9.2 Conguring the CompTrol Interface for program 3 ............................................. 42
9.2.1 Connection diagram for program 3 ................................................................... 42
9.2.2 Setting program 3 via DIP switch S1 ................................................................ 44
9.2.3 Setting functions for program 3 via DIP switch S2 ............................................ 44
9.2.4 Setting the analog signal type on S4 and S7 .................................................... 44
9.3 Analog input ........................................................................................................ 44
9.4 Setting the temperature limit value via DIP switch S2 ........................................ 45
9.5 Digital input assignment in program 3................................................................. 46
9.6 Digital output assignment in program 3 .............................................................. 47
10 Program4–temperaturesetpointdenitionwithhotelremote
control function ....................................................................................................... 48
10.1 Description ......................................................................................................... 48
10.2 Conguring the CompTrol Interface for program 4 ............................................ 48
10.2.1 Connection diagram for program 4 ................................................................... 48
10.2.2 Setting program 4 via DIP switch S1 ................................................................ 50
10.2.3 Setting functions for program 4 via DIP switch S2 ............................................ 50
10.2.4 Setting the analog signal type on S4 and S7 .................................................... 50
10.3 Analog input ....................................................................................................... 50
10.4 Digital input assignment in program 4 ............................................................... 52
10.5 Digital output assignment in program 4 ............................................................. 52
