Product Specifications
Samsung Electronics 17
■ DVM S Premium Energy efficiency type
System Model Capacity of Single Unit (HP)
Capa Code No. of Modules 8HP 10HP 12HP 14HP 16HP 18HP 20HP 22HP 24HP 26HP 28HP 30HP
8HP AM080JXVHGH/EU 1 1
10HP AM100JXVHGH/EU 1 1
12HP AM120JXVHGH/EU 1 1
14HP AM140KXVGGH/EU 1 1
16HP AM160KXVGGH/EU 1 1
18HP AM180KXVGGH/EU 1 1
20HP AM200KXVGGH/EU 1 1
22HP AM220KXVGGH2EU 2 1 1
24HP AM240KXVGGH2EU 2 2
26HP
AM260KXVGGH2EU 2 1 1
28HP AM280KXVGGH2EU 2 1 1
30HP
AM300KXVAGH2EU 2 1 1
32HP
AM320KXVGGH2EU 2 1 1
34HP
AM340KXVGGH2EU 3 2 1
36HP
AM360KXVGGH2EU 2 2
38HP
AM380KXVGGH2EU 2 1 1
40HP
AM400KXVGGH2EU 3 1 1 1
42HP
AM420KXVGGH2EU 3 1 1 1
44HP
AM440KXVGGH2EU 3 1 2
46HP
AM460KXVGGH2EU 3 1 1 1
48HP
AM480KXVGGH2EU 3 1 2
50HP
AM500KXVGGH2EU 3 1 2
52HP
AM520KXVGGH2EU 3 1 1 1
54HP
AM540KXVGGH2EU 3 1 1 1
56HP
AM560KXVGGH2EU 3 1 1 1
58HP
AM580KXVGGH2EU 3 1 1 1
60HP
AM600KXVGGH2EU 3 2 1
62HP
AM620KXVGGH2EU 4 1 3
64HP
AM640KXVGGH2EU 4 1 2 1
66HP
AM660KXVGGH2EU 4 1 3
68HP
AM680KXVGGH2EU 4 1 3
70HP
AM700KXVGGH2EU 4 1 2 1
72HP
AM720KXVGGH2EU 4 4
74HP
AM740KXVGGH2EU 4 3 1
76HP
AM760KXVGGH2EU 4 2 2
78HP
AM780KXVGGH2EU 4 1 3
80HP
AM800KXVGGH2EU 4 3 1
82HP
AM820KXVGGH2EU 4 2 1 1
84HP
AM840KXVGGH2EU 4 1 2 1
86HP
AM860KXVGGH2EU 4 1 1 1 1
88HP
AM880KXVGGH2EU 4 1 1 1 1
90HP AM900KXVGGH2EU 4 1 1 2
▶ Make sure to use an indoor unit that is compatible with DVM S.
▶ Indoor units can be connected within the range indicated in following table.
▶ If the total capacity of the connected indoor units exceeds the indicated maximum capacity, cooling and heating capacity of the indoor unit may
decrease.
▶ Total capacity of the connected indoor units can be allowed from 50% to 130% of the total outdoor unit capacity.
0.5 × Σ( Outdoor unit capacity) ≤ Total capacity of the connected indoor units ≤ 1.3 × Σ( Outdoor unit capacity)
※ You can connect maximum 64 indoor units to the outdoor unit. Maximum quantity of connectable indoor unit is set to 64 since outdoor unit only
support up to 64 communication address. Indoor unit address can be assigned from 0~63. If the indoor unit address was assigned from 64~79, E201
error will occur.
※ Maximum 32 Wall-mount type indoor units with EEV (AMSSSFNQDEHS, AMSSSJNVDKHS) can be connected.
▶ In case of combining modules more than 90HP, please consult the manufacturer when connecting the indoor unit and deciding on piping length in
accordance with design of the building.
2-2 Model names of Indoor/Outdoor Unit (cont.)
2-2-1 Outdoor unit combination (cont.)
