Samsung Electronics 18
Product Specifications
■ DVM S Premium compact type (Heat recovery)
System Model
Capacity of Single Unit (HP)
Capa Code
No. of Modules
8HP 10HP 12HP 14HP 16HP 18HP 20HP 22HP 24HP 26HP 28HP 30HP
8HP AM080JXVHGR/EU 1 1
10HP AM100JXVHGR/EU 1 1
12HP AM120JXVHGR/EU 1 1
14HP AM140JXVHGR/ET 1 1
16HP AM160JXVHGR/ET 1 1
18HP AM180JXVHGR/ET 1 1
20HP AM200JXVHGR/ET 1 1
22HP AM220JXVHGR/ET
1 1
24HP AM240MXVGNR/ET
1 1
26HP AM260MXVGNR/ET
1
1
28HP AM280MXVGNR/ET
1 1
30HP AM300MXVANR/ET
1 1
32HP AM320MXVGNR1ET
2
1
1
34HP AM340MXVGNR1ET
2
1
1
36HP AM360MXVGNR1ET
2 1 1
38HP AM380MXVGNR1ET 2
1 1
40HP AM400MXVGNR1ET
2 1 1
42HP AM420MXVGNR1ET
2 1 1
44HP AM440MXVGNR1ET
2 1 1
46HP AM460MXVGNR1ET
2 1 1
48HP AM480MXVGNR1ET
2 1 1
50HP AM500MXVGNR1ET
2 1 1
52HP AM520MXVGNR1ET
2 1 1
54HP AM540MXVGNR1ET
2 1 1
56HP AM560MXVGNR1ET
2 1 1
58HP AM580MXVGNR1ET
2 1 1
60HP AM600MXVGNR1ET
2 2
62HP AM620MXVGNR1ET
3 1 1 1
64HP AM640MXVGNR1ET
3 1 1 1
66HP AM660MXVGNR1ET
3 1 1 1
68HP AM680MXVGNR1ET
3 1 1 1
70HP AM700MXVGNR1ET
3 1 1 1
72HP AM720MXVGNR1ET
3 1 1 1
74HP AM740MXVGNR1ET
3 2 1
76HP AM760MXVGNR1ET
3 1 1 1
78HP AM780MXVGNR1ET
3 1 1 1
80HP AM800MXVGNR1ET
3 1 1 1
82HP AM820MXVGNR1ET
3 1 2
84HP AM840MXVGNR1ET
3 1 2
86HP AM860MXVGNR1ET
3 1 2
88HP AM880MXVGNR1ET
3 1 2
90HP AM900MXVGNR1ET
3 3
▶ Make sure to use an indoor unit that is compatible with DVM S.
▶ Indoor units can be connected within the range indicated in following table.
▶ If the total capacity of the connected indoor units exceeds the indicated maximum capacity, cooling and heating capacity of the indoor unit may
decrease.
▶ Total capacity of the connected indoor units can be allowed from 50% to 130% of the total outdoor unit capacity.
0.5 × Σ( Outdoor unit capacity) ≤ Total capacity of the connected indoor units ≤ 1.3 × Σ( Outdoor unit capacity)
※ You can connect maximum 64 indoor units to the outdoor unit. Maximum quantity of connectable indoor unit is set to 64 since outdoor unit only
support up to 64 communication address. Indoor unit address can be assigned from 0~63. If the indoor unit address was assigned from 64~79, E201
error will occur.
※ Maximum 32 Wall-mount type indoor units with EEV (AMSSSFNQDEHS, AMSSSJNVDKHS) can be connected.
▶ In case of combining modules more than 90HP, please consult the manufacturer when connecting the indoor unit and deciding on piping length in
accordance with design of the building.
2-2 Model names of Indoor/Outdoor Unit (cont.)
2-2-1 Outdoor unit combination (cont.)
