■ DVM S Premium energy efficiency type (Heat recovery)
System Model
Capacity of Single Unit (HP)
Capa Code
No. of Modules
8HP 10HP 12HP 14HP 16HP 18HP 20HP 22HP 24HP 26HP 28HP 30HP
8HP AM080JXVHGR/EU 1 1
10HP AM100JXVHGR/EU 1 1
12HP AM120JXVHGR/EU 1 1
14HP AM140JXVHGR/ET 1 1
16HP AM160JXVHGR/ET 1 1
18HP AM180JXVHGR/ET 1 1
20HP AM200JXVHGR/ET 1 1
22HP AM220MXVGNR2ET
2
1
1
24HP AM240MXVGNR2ET
2 2
26HP AM260MXVGNR2ET
2
1 1
28HP AM280MXVGNR2ET
2
1
1
30HP AM300MXVGNR2ET
2
1
1
32HP AM320MXVGNR2ET
2 1 1
34HP AM340MXVGNR2ET
3
2
1
36HP AM360MXVGNR2ET
2 2
38HP AM380MXVGNR2ET 2
1 1
40HP AM400MXVGNR2ET
3 1 1 1
42HP AM420MXVGNR2ET
3 1 1 1
44HP AM440MXVGNR2ET
3 1 2
46HP AM460MXVGNR2ET
3 1 1 1
48HP AM480MXVGNR2ET
3 1 2
50HP AM500MXVGNR2ET
3 1 2
52HP AM520MXVGNR2ET
3 1 1 1
54HP AM540MXVGNR2ET
3 1 1 1
56HP AM560MXVGNR2ET
3 1 1 1
58HP AM580MXVGNR2ET
3 1 1 1
60HP AM600MXVGNR2ET
3 2 1
62HP AM620MXVGNR2ET
4 1 3
64HP AM640MXVGNR2ET
4 1 2 1
66HP AM660MXVGNR2ET
4 1 3
68HP AM680MXVGNR2ET
4 1 3
70HP AM700MXVGNR2ET
4 1 2 1
72HP AM720MXVGNR2ET
4 4
74HP AM740MXVGNR2ET
4 3 1
76HP AM760MXVGNR2ET
4 2 2
78HP AM780MXVGNR2ET
4 1 3
80HP AM800MXVGNR2ET
4 3 1
82HP AM820MXVGNR2ET
4 2 1 1
84HP AM840MXVGNR2ET
4 1 2 1
86HP AM860MXVGNR2ET
4 1 1 1 1
88HP AM880MXVGNR2ET
4 1 1 1 1
90HP AM900MXVGNR2ET
4 1 1 2
▶ Make sure to use an indoor unit that is compatible with DVM S.
▶ Indoor units can be connected within the range indicated in following table.
▶ If the total capacity of the connected indoor units exceeds the indicated maximum capacity, cooling and heating capacity of the indoor unit may
decrease.
▶ Total capacity of the connected indoor units can be allowed from 50% to 130% of the total outdoor unit capacity.
0.5 × Σ( Outdoor unit capacity) ≤ Total capacity of the connected indoor units ≤ 1.3 × Σ( Outdoor unit capacity)
※ You can connect maximum 64 indoor units to the outdoor unit. Maximum quantity of connectable indoor unit is set to 64 since outdoor unit only
support up to 64 communication address. Indoor unit address can be assigned from 0~63. If the indoor unit address was assigned from 64~79, E201
error will occur.
※ Maximum 32 Wall-mount type indoor units with EEV (AMSSSFNQDEHS, AMSSSJNVDKHS) can be connected.
▶ In case of combining modules more than 90HP, please consult the manufacturer when connecting the indoor unit and deciding on piping length in
accordance with design of the building.
