Samsung Electronics 20
Product Specifications
■ DVM S Standard type
System Model
Capacity of Single Unit (HP)
Capa Code
No. of Modules 8HP 10HP 12HP 14HP
16HP 18HP 20HP 22HP 24HP 26HP 28HP 30HP
8HP
AM080JXVAGH 1 1
10HP AM100JXVAGH 1 1
12HP AM120JXVAGH 1 1
14HP AM140KXVAGH 1 1
16HP AM160KXVAGH 1 1
18HP AM180KXVAGH 1 1
20HP AM200KXVAGH 1 1
22HP AM220KXVAGH
1 1
24HP AM240KXVAGH
1 1
26HP AM260KXVAGH
1
1
28HP AM280KXVAGH
1 1
30HP AM300KXVAGH
1 1
32HP AM320KXVAGH
2
1
1
34HP AM340KXVAGH
2
1
1
36HP AM360KXVAGH
2 1 1
38HP AM380KXVAGH 2
1 1
40HP AM400KXVAGH
2 1 1
42HP AM420KXVAGH
2 1 1
44HP AM440KXVAGH
2 2
46HP AM460KXVAGH
2 1 1
48HP AM480KXVAGH
2 1 1
50HP AM500KXVAGH
2 1 1
52HP AM520KXVAGH
2 1 1
54HP AM540KXVAGH
2 1 1
56HP AM560KXVAGH
2 1 1
58HP AM580KXVAGH
2 1 1
60HP AM600KXVAGH
2 2
62HP AM620KXVAGH
3 1 1 1
64HP AM640KXVAGH
3 1 1 1
66HP AM660KXVAGH
3 1 1 1
68HP AM680KXVAGH
3 1 1 1
70HP AM700KXVAGH
3 1 1 1
72HP AM720KXVAGH
3 1 1 1
74HP AM740KXVAGH
3 2 1
76HP AM760KXVAGH
3 1 1 1
78HP AM780KXVAGH
3 1 1 1
80HP AM800KXVAGH
3 1 1 1
82HP AM820KXVAGH
3 1 2
84HP AM840KXVAGH
3 1 2
86HP AM860KXVAGH
3 1 2
88HP AM880KXVAGH
3 1 2
90HP AM900KXVAGH
3 3
▶ Make sure to use an indoor unit that is compatible with DVM S.
▶ Indoor units can be connected within the range indicated in following table.
▶ If the total capacity of the connected indoor units exceeds the indicated maximum capacity, cooling and heating capacity of the indoor unit may
decrease.
▶ Total capacity of the connected indoor units can be allowed from 50% to 130% of the total outdoor unit capacity.
0.5 × Σ( Outdoor unit capacity) ≤ Total capacity of the connected indoor units ≤ 1.3 × Σ( Outdoor unit capacity)
※ You can connect maximum 64 indoor units to the outdoor unit. Maximum quantity of connectable indoor unit is set to 64 since outdoor unit only
support up to 64 communication address. Indoor unit address can be assigned from 0~63. If the indoor unit address was assigned from 64~79, E201
error will occur.
※ Maximum 32 Wall-mount type indoor units with EEV (AMSSSFNQDEHS, AMSSSJNVDKHS) can be connected.
▶ In case of combining modules more than 90HP, please consult the manufacturer when connecting the indoor unit and deciding on piping length in
accordance with design of the building.
2-2 Model names of Indoor/Outdoor Unit (cont.)
2-2-1 Outdoor unit combination (cont.)
To Next Page
