Installer reference guide / Mono tank integrated type 167
8.5 Testing operations and concrete curing function
Testing operations
AE080BXYD**, AE120BXYD**, AE140BXYD**
1 Check the power supply between the outdoor unit and the auxiliary circuit breaker.
– 1 phase power supply : L, N
– 3 phases power supply : R,S,T,N
2 Check the control panel
– Check that you have connected the power and communication cables correctly. (If the power cable and
communication cables one mixed up or connected incorrectly, the PCB will be damaged.)
– Check the temp. sensor, drain pump/hose, and display are connected correctly.
3 Press K1 or K2 on the outdoor unit PCB to run the test mode and stop.
K1 (Number of Press) KEY operation 7-segment display
1 time
Trial operation in Heating mode “K” “1” “BLANK“ “BLANK“
2 times
Vacuuming (Outdoor unit address 1) “K” “2” “BLANK “ “1“
3 times
Inverter Fault Detection (Comp #1) “K” “3” “I “ “1“
4 times
End Key operation -
K2 (Number of Press) KEY operation 7-segment display
1 time
Trial operation in Cooling mode “K” “4” “BLANK“ “BLANK“
2 times
Discharge mode of DC link voltage
“K” ”5” ”o” ”k” (1phase)
“K” ”5” ”n” ”A” (3phase)
3 times
Forced defrost operation “K” “6” “BLANK“ “BLANK“
4 times
Inverter compressor 1 check “K” “7” “BLANK“ “BLANK“
5 times
End Key operation -
K3 (Number of Press) KEY operation 7-segment display
1 time
Intialize (Reset) setting Same as initial state
1 32 4
ON
YKO
1 32 4
ON
YKO
1 32 4
ON
YKO
K5 K6 K7 K8
K5 K6 K7 K8
7-segment display
KEY (K1~K4)
4 View Mode : When the K4 switch is pressed, you can see information about our system state as below.
K4 (Number of press) KEY operation
Display on segment
SEG 1 SEG 2,3,4
1 time
Capacity of outdoor unit 1 16HP g 0,1,6
2 times
Order frequency of the compressor 2 120Hz g 1,2,0
3 times
High pressrue (kg/cm
2
) 3 15.2K g 152
4 times
Low pressrue (kg/cm
2
) 4 4.3K g 043
5 times
Discharge temperature Compressor 5
6 times
IPM temperature 6
7 times
CT sensor value 7 2A g 020
8 times
Suction temperature 8
9 times
COND OUT temperature 9
10 times
EVA in temperature A
11 times
Compressor top temperature B
12 times
Outdoor temperature C
13 times
EVI inlet temperature D
14 times
EVI outlet temperature E
15 times
Main EEV step F 2000 g 200
16 times
EVI EEV step G 300 g 300
17 times
Fan step (ssr or bldc) H 13Step g 0,1,3
18 times
Current frequency Compressor I 120Hz g 1,2,0
19 times
EVI SOL EEV step J 300 g 300
20 times
Inverter pump output K 100% g 100
K4 (Number of press)
Press and hold the K4
to enter the setting
Displayed content
Display on segment
Page 1 Page 2
1 time
Main version MAIN Version (ex. 1412)
2 times
Inverter version INV Version (ex. 1412)
3 times
EEP version EEP Version (ex. 1412)
4 times
Automatically assigned address of the units AUTO
SEG1,2 SEG3,4
Indoor unit : “A“, ”0”
MCU : “C“, “1“
Address (ex:07)
5 times
Manually assigned address of the units MANU
SEG1,2 SEG3,4
Indoor unit : “A“, ”0” Address (ex:15)
To Next Page
