8. System configuration
Installer reference guide / Mono tank integrated type 169
Number of press Display contents
Display
Units
Segment 1 Segment 2 Segment 3 Segment 4
4 times
Outdoor air sensor 4 +/- 10s digit 1s digit °C
5 times Discharge sensor 5 100s digit 10s digit 1s digit °C
6 times Eva in sensor 6 +/- 10s digit 1s digit °C
7 times Inlet water sensor 7 +/- 10s digit 1s digit °C
8 times Outlet water sensor 8 +/- 10s digit 1s digit °C
9 times Cond sensor 9 +/- 10s digit 1s digit °C
10 times Current A 10s digit 1s digit First decimal A
11 times Fan RPM B 1000s digit 100s digit 10s digit rpm
12 times
Target discharge
temperature
C 100s digit 10s digit 1s digit °C
13 times EEV D 1000s digit 100s digit 10s digit step
14 times Protective control E
0 : Cooling
1 : Heating
Protective
control
0 : No
protective
control
1: Freezing
2: Defrosting
3: Over-load
4: Discharge
5: Total current
Frequency
status
0: Normal
1: Hold
2: Down
3: Up_limit
4: Down_limit
-
15 times IPM temp. F +/- 10s digit 1s digit °C
long-1 time Main Micom version Year(Dec) Month(Hex) Day(two digit) Day(One digit) -
long-1 and 1 times Inverter Micom version Year(Dec) Month(Hex) Day(two digit) Day(One digit) -
long-1 and 2 times EEPROM version Year(Dec) Month(Hex) Day(two digit) Day(One digit) -
