Installer reference guide / Mono tank integrated type 38
Outdoor unit installation on a bracket suspended from a wall
• Ensure the wall will be able to support the suspended weight of both rack and outdoor unit.
• Install the bracket close to a constructional column as much as possible.
• Install the proper grommet in order to reduce noise and residual vibration transferred by the outdoor unit towards the wall.
Soft rubber designed to cut off
vibration from the bracket to the
wall. (not supplied with product)
WARNING
• Be sure to remove the transport pallet below the bottom side of the unit base panel before fixing the
bolt. Its sole purpose it to carry the product during transport, it has no installation value. Please discard
the pallet in accordance to local waste regulations once the unit is correctly installed.
