Samsung PROXPRESS M332 SERIES Service Manual

4.Troubleshooting
►ErrorCode
U2-1112
U2-1113
►Errormessage
Error#U2-1111Turnoffthenon.
Error#U2-1113Turnoffthenon.
►Symptom
LSUMotordoesnotworknormally.
►Troubleshootingmethod
1)ExecutetheLSUmotortestinEDCmode.CheckLSUmotoroperationsound.
2)Ifthereisnosound,removetherightcover.CheckiftheLSUharnessisconnectedonthemainboardproperly.
(picture-1)
3)IfitisOK,removethetopcover.CheckiftheLSUharnessisconnectedonLSUboardproperly.(picture-2,3)
4)CheckiftheLSUharnessisdefective.(picture-4)
5)ReconnecttheLSUharnessandthenexecutetheLSUmotortestagain.
6)Iftheproblempersists,replacetheLSU(JC97-04065A).
7)IftheproblempersistsafterreplacingLSU,replacethemainboard.
