Samsung PROXPRESS M332 SERIES - HVPS Board

2.ProductSpecications
2.2.5.9.HVPSboard
HighV oltagePowerSupply(HVPS)boardgenerateshigh-voltagechannelswhichincludesMHV ,DEV ,BLADE,SUPPLY ,
OPC,THVandFUSERBIAS.
•Connection
1MainInterface
2MHV(-1240V)
3DEV(-338V)
4BLADE(-389V)
5SUPPLY(-489V)
6OPC(-51V)
7THV(+1315V ,-1000V)
8FUSERBIAS(240V)
•Information
-PartCode:JC44–00197A
-PartName:HVPS
