2.ProductSpecications
2.2.6.EngineFirmwareControlAlgorithm
2.2.6.1.Feeding
Iffeedingfromacassette,thedriveofthepickuprolleriscontrolledbycontrollingtheclutch.Theon/offoftheclutchis
controlledbycontrollingthegeneraloutputportortheexternaloutputport.Whilepapermoves,occurrenceofJam
isjudgedasbelow.
ItemDescription
JAM0•Afterpickingup,paperdoesnotreachtheFeedSensorwithinapredeterminedtime.
•Afterpickingup,ifthefeedsensorisnoton,re-pickupwillbeinitiated..Afterre-pickingup,ifthe
feedsensorisnotonaftercertaintime,itisJAM0.
•Eventhoughthepaperreachestothefeedsensor,thefeedsensordoesnotdetecttheleadedgeof
thepaper.
JAM1•Aftertheleadingedgeofthepaperpassesthefeedsensor,thetrailingedgeofthepaperdoesnotclear
thesensorafterpredeterminedperiodoftime.
•Aftertheleadingedgeofthepaperpassesthefeedsensor,thepapercannotreachtheexitsensor
afterpredeterminedperiodoftime.
*Thepaperexistsbetweenthefeedsensorandtheexitsensor.
JAM2•Thetrailingedgeofthepaperdoesnotcleartheexitsensorwithinapredetermined.
2.2.6.2.Transfer
Thechargingvoltage,developingvoltageandthetransfervoltagearecontrolledbyPWM(PulseWidthModulation).The
eachoutputvoltageischangeableduetothePWMduty.Thetransfervoltageadmittedwhenthepaperpassesthetransfer
rollerisdecidedbyenvironmentconditions.Theresistancevalueofthetransferrollerischangedduetothesurrounding
environmentortheenvironmentoftheset,andthevoltagevalue,whichchangesduetotheenvironment,ischangedthrough
theADconverter.Thevoltagevalueforimpressingtothetransferrollerisdecidedbythechangedvalue.
Copyright©1995-2016SAMSUNG.Allrightsreserved.2-35
