Samsung PROXPRESS M332 SERIES Service Manual

3.DisassemblyandReassembly
3.3.19.3.SCFMainMotor
1.RemovetheSCFrightcover.(Referto3.3.19.1)
2.Unplugthemotorconnector.
3.Remove4screws.
4.ReleasetheSCFmainmotor.
3.3.19.4.SCFClutch
1.RemovetheSCFrightcover.(Referto3.3.19.1)
2.Unplugtheclutchconnector.
3.Remove2E-Ringsand2Bushes.
4.Remove2screws.
5.Releasetheclutchbracket.
6.RemovetheSCFclutch.
3-21Copyright©1995-2016SAMSUNG.Allrightsreserved.
