2.ProductSpecications
2.2.5.3.OPEController
TheOPEControlleriscomposedofanOPEMICOM,twostatusLED,ECOLED,powerLED,NavigationLED,WPS
LED(M3820DW/3825DW,modelonly),16x2lineLCD(M382xND/DW,M402xND),4.3inchTFTLCD(M402xNX),
andsomekeys.
OPEcommunicateswithmaincontrollerviaUART/USB.
M3320ND/3325ND/3820D/3825DmodelOPEiscomposedofLEDsandKEYswithoutLCD.
OPEControllerDiagram
OPEControllerImage
M332xND/M382xDM382xND,DW/M402xNDM402xNX
•PartCode:
JC92–02609A
•PBAName:
OPE-LED
•PartCode:
JC92–02608A
•PBAName:
OPE-LCD
1)PartCode:JC92–02610A
PBAName:PBA-OPEMAIN
2)PartCode:JC07–0017A
PBAName:LCD
3)PartCode:JC92–02609A
PBAName:OPE-LED
