2.ProductSpecications
2.2.4.4.LSU(LaserScanningUnit)
ItisthecorepartoftheLBPwhichswitchesfromthevideodatareceivedtothecontrollertotheelectrostaticlatentimage
ontheOPCdrumbycontrollinglaserbeam,exposingOPCdrum,andturningprincipleofpolygonmirror.TheOPCdrumis
turnedwiththepaperfeedingspeed.TheHSYNCsignaliscreatedwhenthelaserbeamfromLSUreachestheendofthe
polygonmirror,andthesignalissenttothecontroller.ThecontrollerdetectstheHSYNCsignaltoadjusttheverticallineof
theimageonpaper.Inotherwords,aftertheHSYNCsignalisdetected,theimagedataissenttotheLSUtoadjusttheleft
marginonpaper.Theonesideofthepolygonmirrorisonelineforscanning.
OPC Drum
Photo Diode
LD Driver circit
Protector panel
LD(Laser Diode)
Polygon Mirror
Polygon Motor
Motor Driver
2-18Copyright©1995-2016SAMSUNG.Allrightsreserved.
