2.ProductSpecications
2.2.4.Systemlayout
ThismodelconsistsoftheEngineparts,HardwareandFirmware.Theenginepartsconsistsofthemechanicalparts
comprisingFrame,Duplex,Tonercartridge,Driveunit,Transferroller,Fuser,Cassette.TheHardwarepartconsistsofthe
maincontrolboard,powerboard,operationpanel,PCInterface.
1
2
3
4
7
6
8
5
11
10
9
1LSU(LaserScanningUnit)
2TonerCartridge
3Regi.Roller
4MP
5FeedRoller
6Pick-UpRoller
7Cassette
8DuplexUnit
9Fuser
10ExitRoller1
11ExitRoller2
