Samsung PROXPRESS M332 SERIES Service Manual

3.DisassemblyandReassembly
3.3.19.7.SCFMainDriveUnit
1.RemovetheSCFrightcover.(Referto3.3.19.1)
2.RemovetheSCFclutchbracket.(Referto3.3.19.4)
3.Unplugthemainmotorconnector.
4.Remove4screws.
5.RemovetheSCFmaindriveunit.
3.3.19.8.SCFLiftAssy
1.RemovetheSCFrightcover.(Referto3.3.19.1)
2.RemovetheSCFmainboard.(Referto3.3.20.2
)
3.Opentheharnessclamp.
4.Remove4screws.
5.ReleasetheSCFLiftAssy.
