2.ProductSpecications
MainControllerconnectioninformation
•Connection
NoDescription
12LINELCDOPE
(ExceptLEDOPEmodel)
2COVEROPENSENSOR
(Onlyfor
M3325ND/3825ND/3825DW/4025ND)
3LEDOPE
(Onlyfor
M3320ND/3325ND/3820D/3825D)
4CRUM
5FUSER
6TONERCRUM
(Onlyfor
M3325ND/3825ND/3825DW/4025ND)
7WLAN
(OnlyforM3820DW/3825DW)
8OUTBINFULL/REARCOVER
OPEN
9NETWORK
(NotapplyforM3820D/3825D)
10USBDEVICE
NoDescription
11P ARALLELPWR
12EXITSENSOR
13AIRTEMP
14FANSMPS
15MAINMOTOR
16SCF(option)
17DEBUG
18SMPSSIGNAL
19SMPSPOWER
20MP
(Notapplyfor
M3320ND/3325ND/3820D/3825ND)
21LSU
22FANMAIN
23HVPS
24SENSORI/F
25DDR3SO-DIMM
