S&C IntelliRupter PulseCloser User Manual

Control Point Number
Enter the DNP control point number that activates the Transfer Trip mode in the remote
device. (Range: 0-255; Step: 1; Default: 0)
Protocol
When the remote device is an S&C product, select the Peer-to-Peer (P2P) protocol. The P2P
protocol allows the remote S&C device to report the actual opening of the remote device
to the sending device to allow the IntelliTeam system to proceed with transfer events.
DNP Control Type
Enter the appropriate control type for the congured Control PT Number setpoint:
Pulse On, Latch On or Breaker Close. When received, the remote control will issue
an Open command to the distributed generation switch.
Commission Test
Selecting the Execute command from the drop-down menu sends a Transfer Trip
command to the target device(s) in the exact same manner that will occur when the
command is sent during normal operation.
NOTICE
Performing a commission test will operate the target device by sending it an Open
command. A Close command must be sent to the device and any alarms cleared
to put the device in the Ready state.
Test Result
“Pass,” “Pending,” “Bad Response,” or “No Result” are indicated for the sent Prohibit
Restoration command. “Pass” means the local device received an acknowledgement from
the remote device before the Retry Timer expired. “Pending” means the local device sent
out the test command but is still awaiting a response. “Bad Response” means either the
remote device rejected the command or the Retry Timer expired before the local device
received an acknowledgement. “No Result” means no tests have been performed yet.
Remote Transfer Trip
Selecting the Enabled state allows commands from this device to be sent to all non-zero
RTU addresses listed on the Remote Transfer Trip List. Selecting the Disabled state
blocks the commands. When there are no distributed generation resources listed on the
Remote Transfer Trip List, set this to the Disabled state.
Control Relay Pulse On Time
This sets the control relay output block on time for the distributed generation devices that
receive DNP3 transfer trip control requests. Each count is 1 mS. (Range: 0-4,294,967,295;
Step: 1; Default:1)
Control Relay Pulse Off Time
This sets the control relay output block off time for the distributed generation devices that
receive DNP3 transfer trip control requests. Each count is 1 mS. (Range: 0-4,294,967,295;
Step: 1; Default:0)
