Review the “Computer Requirements” and “Software Installation” sections in
Instruction Sheet 766-571, “IntelliRupter® PulseCloser® Fault Interrupter:
Software Installation.”
NOTICE
Install and use only the IntelliLink Setup Software supplied for IntelliRupter fault
interrupter. IntelliLink Setup Software furnished with other S&C products cannot be
used to access an IntelliRupter fault interrupter.
NOTICE
A remote or local upgrade puts a control into the Prohibit Restoration state. When
upgrading controls in an IntelliTeam SG system, use the following procedure:
STEP 1. Upgrade the control software. This can be done with IntelliLink Setup
Software.
STEP 2. After the upgrade, verify all settings were preserved.
STEP 3. Use IntelliTeam Designer Version 6.0.x.x to re-push IntelliTeam SG system
configurations to all FeederNets that have updated devices.
STEP 4. If a device is an open point, push the configuration to both FeederNets for
that device.
STEP 5. Verify the team configurations.
STEP 6. For IntelliNode™ Interface Modules only, set the External Device Data
Updated mode to the Running setting.
STEP 7. Enable the Automatic Restoration mode on all upgraded controls.
Coordinaide software can plot various TCC curves for a protection overcurrent element
direction. The curves appropriate for both the upstream and downstream protective
devices can then be selected, and their parameters downloaded to a Setpoints Group File
for uploading to the IntelliRupter fault interrupter control. A Setpoints Group File can
also be downloaded from a control and opened using Coordinaide software for evaluation.
The link to Coordinaide software is located on the S&C website at:
sandc.com/en/support/coordinaide/. When selected, the link the opening page has a
brief description of the protection applications Coordinaide software can handle. When
launching the program, the next page contains the Conditions of Use disclaimer, the
minimum Web browser requirements, and a link to the Coordinaide software users guide.
After agreeing to the Conditions of Use, one final click launches the program.
Requirements and
Installation
Coordinaide™—
The S&C Protection
& Coordination
Assistant
S&C Instruction Sheet 766-530 9
IntelliRupter
®
Fault Interrupter Software
