Phase Overcurrent
The Phase Overcurrent element trips the IntelliRupter fault interrupter when current
on one or more phases exceeds the pickup value for the time value set by the Inverse
Curve or Denite Time settings.
Phase Check box—Select to congure this element.
Inverse SegmentSelect from the drop-down list of inverse curve names or select the
None option. When the None option is selected, only the Denite Time settings will
be used.
Min. TripThis is the current (in primary amperes) at which the inverse curve begins
timing. (Range: 6-16,000; Step: 1) The stated maximum is for 15-kV IntelliRupter fault
interrupters; 27-kV and 38-kV are limited to 12,500 amps maximum.
Min. TimeThis is the time (in seconds) dening the fastest response of the inverse
curve portion of the TCC curve. (Range: 0.000-100.000; Step: 0.001)
Time Mult—This is the time modier for the inverse curve. (Range: 0.01-15.00; Step: 0.01)
Time AdderThis is the time modier for the inverse curve. (Range: -10.000-100.000;
Step: 0.001)
Low Cutoff—This is the current (in primary amperes) at which the TCC curve begins
timing. This value must be equal to or greater than the lowest pickup value of the inverse
curve, the Denite Time 1 element, and the Denite Time 2 element. (Range: 6-16,000;
Step: 1) The stated maximum is for 15-kV IntelliRupter fault interrupters; 27-kV and 38-kV
are limited to 12,500 amps maximum.
ResetSelect the reset method for the inverse curve from the drop-down list:
D/T (Denite Time) or E/M (Electromechanical) mode.
Reset TimeIf the Denite Time reset mode is selected, enter the time delay for the
reset (in seconds). (Range: 0.000-600.000; Step: 0.001)
Denite Time 1 Min. TripThis is the current (in primary amperes) at which the
Denite Time 1 element picks up. (Range: 6-16,000; Step: 1) The stated maximum is
for 15-kV IntelliRupter fault interrupters; 27-kV and 38-kV are limited to 12,500 amps
maximum.
Denite Time 1 Min. TimeThis is the time delay (in seconds) after which the Denite
Time 1 element trips. (Range: 0.000-600.000; Step: 0.001)
Denite Time 2 Min. TripThis is the current (in primary amperes) at which the
Denite Time 2 element picks up. (Range: 6-16,000; Step: 1) The stated maximum is
for 15-kV IntelliRupter fault interrupters; 27-kV and 38-kV are limited to 12,500 amps
maximum.
Denite Time 2 Min. TimeThis is the time delay (in seconds) after which the Denite
Time 2 element trips. (Range: 0.000-600.000; Step: 0.001)
S&C Instruction Sheet 766-530 63
Protection Setup
