Low Cutoff—This is the current (in primary amperes) at which the TCC curve begins
timing. This value must be equal to or greater than the lowest pickup value of the inverse
curve, the Denite Time 1 element, and the Denite Time 2 element. (Range: 6-16,000;
Step: 1) The stated maximum is for 15-kV IntelliRupter fault interrupters; 27-kV and
38-kV models are limited to 12,500 amps maximum.
Reset—Select the reset method for the inverse curve from the drop-down list: select the
D/T (Denite Time) or E/M (Electromechanical) mode.
Reset Time—When the Denite Time reset mode is selected, enter the time delay for
the reset (in seconds). (Range: 0.000-600.000; Step: 0.001)
Denite Time 1 Min Trip—This is the current (in primary amperes) at which the
Denite Time 1 element picks up. (Range: 6-16,000; Step: 1) The stated maximum
is for 15-kV IntelliRupter fault interrupters; 27-kV and 38-kV models are limited to
12,500 amps maximum.
Denite Time 1 Min. Time—This is the time delay (in seconds) after which the Denite
Time 1 element trips. (Range: 0.000-600.000; Step: 0.001)
Denite Time 2 Min. Trip—This is the current (in primary amperes) at which the
Denite Time 2 element picks up. (Range: 6-16,000; Step: 1) The stated maximum
is for 15-kV IntelliRupter fault interrupters; 27-kV and 38-kV models are limited to
12,500 amps maximum.
Denite Time 2 Min. Time—This is the time delay (in seconds) after which the Denite
Time 2 element trips. (Range: 0.000-600.000; Step: 0.001)
Negative Sequence
The Negative Sequence element will trip the IntelliRupter fault interrupter if the
negative-sequence component of the three-phase elements exceeds the pickup value for
the time value set by the inverse curve or the Denite Time setting.
Negative Sequence Check box—Select this box to congure the Negative Sequence
element.
Inverse Segment—Select from the drop-down list of inverse curve names or select
the None option. When the None option is selected, only the Denite Time settings
will be used.
Min. Trip—This is the current (in primary amperes) at which the inverse curve begins
timing. (Range: 6-16,000; Step: 1) The stated maximum is for 15-kV IntelliRupter fault
interrupters; 27-kV and 38-kV models are limited to 12,500 amps maximum.
Min. Time—This is the time (in seconds) dening the fastest response of the inverse
curve portion of the TCC curve. (Range: 0.000-100.000; Step: 0.001)
Time Mult.—This is the time multiplier for the inverse curve. (Range: 0.01-15.00;
Step: 0.001)
Time Adder—This is the time adder for the inverse curve. (Range: -10.000-100.000;
Step: 0.001)
Low Current Cutoff—This is the current (in primary amperes) at which the TCC curve
begins timing. This value must be equal to or greater than the lowest pickup value of
the inverse curve, the Denite Time 1 element, and the Denite Time 2 element.
(Range: 6-16,000; Step: 1) The stated maximum is for 15-kV IntelliRupter fault interrupters;
27-kV and 8-kV models are limited to 12,500 amps maximum.
90 S&C Instruction Sheet 766-530
