MULTI-PORT OPTICAL POWER METER MPM-210H
15 / 59
3.5. MPM-215 (Power meter module 4 ports with high dynamic range)
The MPM-215 has 4 optical power measuring ports (4 channels). The connector
of the optical input port is a FC connector receptacle. Optical input port will be
recognized as port for measuring optical power and it gets assigned as port
numbers (1,2,3,4) from top to bottom. The MPM-215 enables optical power
measurement for each port with a high dynamic range of 60 dB or more. However,
the MPN-215 cannot be used as same as other modules (MPM-211/212/213) and
it does not support the measurement range switching function.
