MPM-210H OPERATION MANUAL
24 / 59
To set up for Gate way IP, Subnet Mask, IP Address, user needs to set them
by RS232 communication or GPIB communication. (Refers to the 5.5.1.)
When the MPM-210H receives the command, the terminator is recognized
the <LF> and when the MPM-210H sends the command, the terminator is
the <CR><LF>.
* Please use the cable of UL94 V1 or more for TPC / IP communication.
Default Configuration
Item
Command
Default Address
Gate way Address
GW
192.168.1.254
Subnet Mask
SUBNET
255.255.255.0
IP Address
IP
192.168.1.161
Remote port
-
5000
NOTE
When sending each command by the TCP/IP communication, the wait of
10ms needs after sending commands. Please refer to the “5.6.7. Sample
code for “SME mode measurement” for the detail.
5.3. RS-232 Communication
5.3.1 RS-232 Communication Set up
Baud Rate
115200
Data Bits
8 bits
Parity Bit
None
Stop Bit
1
Terminator
LF
Echo
False (Default)
When the echo is valid, sets it by the “ECHO” command. Refer to the section
“5.5.2” for the detail. When the MPM-210H receives the command, the
terminator is recognized the <LF> and when the MPM-210H sends the command,
the terminator is the <CR><LF>.
The Logging function is not available for RS-232 communication.
