MPM-210H OPERATION MANUAL
6 / 59
Contents
Introduction
How to Read the Manual
Instrument Markings
Explanation of Terms
1. Introduction ...................................9
2. Product Composition ..................... 10
3. Panel Descriptions ......................... 11
3.1. Front Panel .................................................................11
3.2. MPM-211 (Power meter module 4 ports) .........................12
3.3. MPM-212 (Power meter module and analog output 2
ports) ........................................................................13
3.4. MPM-213 (Current meter module 4 ports) .......................14
3.5. MPM-215 (Power meter module 4 ports with high dynamic
range) .......................................................................15
3.6. Rear Panel ..................................................................16
4. Installation ................................... 17
4.1. Warning and Caution ...................................................17
4.2. Environment ...............................................................17
4.3. Line Voltage Selection ..................................................18
4.4. Line Fuse ...................................................................18
4.5. Line Cord ...................................................................18
4.6. Zeroing option (To remove electrical offsets) ....................18
4.7. Maximum input optical power ........................................18
4.8. Inserting a module ......................................................19
5. Remote Control ............................. 20
5.1. GPIB Communication ...................................................20
5.2. TCP/IP Communication .................................................21
