MULTI-PORT OPTICAL POWER METER MPM-210H
51 / 59
8. LEV 1 - Set TIA Gain Level.
9. MEAS - Time of measurement.
10. “Delay 20sec + alpha(3 sec)”:
After External Trigger Input “Delay as expected measurement time”
A. STAT? - Check current measurement status
11. STOP - Stop measurement (Option)
12. LOGG? 1,1 - Get measured value
A. Module - 1, port - 1
13. CWAV? - Check the wavelength that should be
calibrated.
14. CWAVPO? - Check the Optical power offset for each
calibrated wavelength.
- Executes wavelength sensitivity calibration using the data that are read
out from “CWAV?” and “CWAVPO?” command. (Refer to the 5.5.5.)
5.6.7. Sample code for SME mode measurement
1. WMOD SWEEP1 - Choose measurement mode
2. WSET 1260,1290,0.01 - Set Sweep Wavelength
3. SPE 10 - Set Sweep Speed
4. LEV 1 - Set TIA Gain Level.
5. TRIG 1 - Choose external trigger.
6. MEAS - Start measurement
7. STAT? - Check current measurement status
8. STOP - Stop measurement (Option)
9. LOGG? 1,1 - Get measured value
NOTE
In Sweep 1 mode, user does not set Average Time. It is calculated from
Sweep speed value and Set wavelength value and applied automatically.
