481
[Settings]
Set the barcode check function.
The setting items are as follows:
Mode
Select the check mode or disable the barcode check function.
Start Position
Adjust the position at which the barcode check starts (position of the barcode checker at which
reading starts).
VOID Print
Set whether to print error marks on the media when a barcode reading error or barcode
comparison error occurs.
Retry Count
Set how many times the printer will try to print and check the same barcode after VOID printing
when a barcode reading error or barcode comparison error occurs.
Appears only if you have selected [Enabled] in the [VOID Print] menu.
Host Notification
Set whether to return the barcode check results to the host from which the print data is sent.
Logs
Manage the barcode check log data saved in the printer.

Table of Contents

Other manuals for SATO CL6NX

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the SATO CL6NX and is the answer not in the manual?

SATO CL6NX Specifications

General IconGeneral
Flash memory2000 MB
Storage mediaFlash
Internal memory256 MB
Built-in barcodesCode 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity2 GB
Cables includedAC
Maximum roll diameter220 mm
Maximum printing width167.5 mm
Printing media thickness0.08 - 0.268 µm
USB portYes
USB connectorUSB Type-A / USB Type-B
Bluetooth version3.0
Serial interface typeRS-232C
USB 2.0 ports quantity2
Connectivity technologyWired & Wireless
Wi-FiNo
Display typeLCD
Product colorBlack
Display diagonal3.5 \
Display resolution320 x 240 pixels
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)30 - 90 %
Operating relative humidity (H-H)30 - 80 %
TypePOS printer
Print speed10 ips
Print technologyDirect thermal / Thermal transfer
Maximum resolution203 x 203 DPI
Weight and Dimensions IconWeight and Dimensions
Depth457 mm
Width338 mm
Height321 mm
Weight20000 g
