Universal inputs
Inputs/outputs (I/O)
4-10
4
Media mapping of UI if they are used as digital inputs



Usage Status of
ag
If contact
is open
Status of
ag
If contact
is closed
UI1GND …UI0…
PCD7.LRxx-P5
DI as dry contact
Dry contact
(GND on UI)
1 0
UI1GND …UI0…
PCD7.LRxx-P5
DI with source operation
Digital
(24 V = on UI)
0 1
4.2.1.5 Programming digital inputs

as common in the program application.
