SBC PCD7.LR P5 Series - Use as Digital Inputs; Digital Input 24 VDC with Source Operation; Digital Input 24 VDC with Sink Operation; Digital Input as Dry Contact

Hardware manual PCD7.LRxx-PG5 room controller │ Document 27-653; version ENG07 │ 2019-03-21
Saia-Burgess Controls AG
Universal inputs
Inputs/outputs (I/O)
4-8
4
4.2.1 Use as digital inputs
 Digital input 24 VDC with source operation
 Digital input 24 VDC with sink operation
 Digital input as dry contact
4.2.1.1 Digital input 24 VDC with source operation
Connection example
Mode selection
DeviceCongurator
UI1GND …UI0…
PCD7.LRxx-P5
DI with source operation
digital
4.2.1.2 Digital input 24 VDC with sink operation
Connection example
Mode selection
DeviceCongurator
UI1GND …UI0…
PCD7.LRxx-P5
DI with sink operation
digital
4.2.1.3 Digital input as dry contact
Connection example
Mode selection
DeviceCongurator
UI1GND …UI0…
PCD7.LRxx-P5
DI as dry contact
dry contact
