Modbus on PCD7.LRxx-P5 RS-485 interfaces
PCD7.LRxx-P5 write Modbus values to PCD 1/2/3
PCD7.LRxx-P5 PCD 1/2/3
PCD7.LRxx-P5 acting as
Modbus client and writing 16-bit
or 32-bit values to the PCD 1/2/3
Media mapping on the PCD 1/2/3 acting as Modbus server:

11112222 hex for PCD Reg
33334444 hex for PCD Reg +1 … as shown on the left side of the table.
PCD7.LRxx-P5
Register
Number
Example of
value stored
on the
PCD7.LRxx-P5
register
Modbus
Holding Register
Number
PCD 1/2/3
Register Number
on the PCD 1/2/3
PCD 1/2/3
Register content if
written with 16 bits
Modbus object
number = PCD
register number
PCD 1/2/3
Register content if
written with 32 bits
Modbus object
range 10001 and
higher must be
used on the PCD
1/2/3.
To access register
600, it is necessary
to access the Mod-
bus object 11201
(2 x 600 + 10001)
PCD 1/2/3
Register content if
written with 32 bits
swapped
Modbus object
range 10001 and
higher must be
used on the PCD
1/2/3.
To access register
600, it is necessary
to access the Mod-
bus object 11201
(2 x 600 + 10001)
PCD Reg 11112222
hex
HR0 / HR1 PCD Reg 0 00002222
hex
11112222
hex
22221111
hex
PCD Reg+1 33334444
hex
HR2 / HR3 PCD Reg 1 00004444
hex
33334444
hex
44443333
hex
PCD Reg+2 55556666
hex
HR4 / HR5 PCD Reg 2 00006666
hex
55556666
hex
66665555
hex
PCD Reg+3 77778888
hex
HR6 / HR7 PCD Reg 3 00008888
hex
77778888
hex
88887777
hex
PCD Reg+4 9999AAAA
hex
HR8 / HR9 PCD Reg 4 00008888
hex
9999AAAA
hex
AAAA9999
hex
PCD Reg+5 BBBBCCCC
hex
HR10 / HR11 PCD Reg 5 0000CCCC
hex
BBBBCCCC
hex
CCCCBBBB
hex
PCD Reg+6 DDDDEEEE
hex
HR12 / HR13 PCD Reg 6 0000EEEE
hex
DDDDEEEE
hex
EEEEDDDD
hex
PCD Reg+7 FFFF1111
hex
HR14 / HR15 PCD Reg 7 00001111
hex
FFFF1111
hex
1111FFFF
hex
PCD Reg+8 22223333
hex
HR16 / HR17 PCD Reg 8 00003333
hex
22223333
hex
33332222
hex
PCD Reg+9 44445555
hex
HR18 / HR19 PCD Reg 9 00005555
hex
44445555
hex
55554444
hex
PCD Reg+10 66667777
hex
HR20 / HR21 PCD Reg 10 00007777
hex
66667777
hex
77776666
hex
PCD Reg+11 88889999
hex
HR22 / HR23 PCD Reg 11 00009999
hex
88889999
hex
99998888
hex
PCD Reg+12 AAAABBBB
hex
HR24 / HR25 PCD Reg 12
--- --- ---
