Scaime eNod4-B - Profibus Version

11/95
User manual SCAIME: NU-soft-eNod4B-E-0716_236704-C.doc
2.4.2 Profibus version
• DIN Version
 PC Connection
 AUX Connection
 PLC Connection
 PROFIBUS-DPV1
 eNodTouch
• BOX Version
Simultaneous
Communication
Profibus
RS485 AUX
USB
Yes*
No
Profibus
Yes*
(*)Simultaneous use of Profibus with USB or RS485AUX can reduce performance of this interface.

PC Connection

PLC
Connection

PROFIBUS
-
DPV1
 PC Connection
 AUX Connection
 PLC Connection
 PROFIBUS-DPV1
 eNodTouch
