13.2.3 Analog output(s) assignment (IO+ version)
The following tables describe the possible assignments.
bits
meaning
note
b
3
b
2
b
1
b
0
analog output assignment
0000
none
the output level does not vary
0001
copy gross weight
Adjustable polarity
0010
copy net weight
0011
level on request
parameter External value to control analog
output will drive analog output
0100
flow rate control output
in loss in weight feeder mode (for extraction
device control)
0101
copy instantaneous flow rate
0110
copy average flow rate
0111
copy average speed
b
4
polarity
0
unipolar
could be set only with gross measurement
1
bipolar
b
7
b
6
b
5
output voltage settings
000
disable
001
0 V - 5 V
010
0 V - 10 V
b
10
b
9
b
8
output current settings
000
disable
001
4 mA - 20 mA
010
0 mA - 20 mA
011
0 mA - 24 mA
100
4 mA - 20 mA alarm 3.6 mA
voltage output is inactive (High-Z state)
13.2.4 External value to control analog output (IO+ version)
If an external device (e.g. PLC) would like to control extraction command through eNod4 analog output, so that output
must be set on level on request function. In this configuration eNod4 will copy external value to control analog
output parameter on analog output in current and voltage.
The external value parameter is expressed in 0.01% of full scale of analog output current or voltage.
